| Model Name |
IPPS-2118-SKL2/KBL5-WP |
| LCD |
|
| Display Type |
21.5" Full HD TFT LCD |
| Resolution |
1920 x 1080 pixel |
| Brightness |
1600 cd/m² (250 cd/m² optional ) |
| LCD Color |
16.7M |
| Pixel Pitch (H/V) |
0.24825mm x 0.24825mm |
| Constrast Ratio |
900:1 |
| Viewing Angle (H/V) |
170°/160°/(typ.) |
| Backlight MTBF (typ.) |
100,000 hrs |
| Touch Screen Type |
P-CAP 10-points |
| System |
|
| CPU |
Intel® Core™ i7-6600U 2.6GHz QC (15W)
Intel® Core™ i5-6300U 2.4GHz DC (15W)
Intel® Core™ i3-6100U 2.3GHz DC (15W)
Intel® Celeron® 3955U 2.0GHz DC (15W)
Intel® 7th Gen Core™ i7/i5/i3 processors (LGA1151) |
| Chipset |
Intel® Skylake-U integrated / Intel® H110 PCH |
| Memory |
1 x 260-pin DDR4 2133MHz SDRAM; max. up to 16GB / 2 x 260-pin DDR4 2133MHz SDRAM; max. up to 32GB |
| Graphic |
Intel® HD Graphics 520/510 / or Intel® HD Gen. 9 Graphics |
| Watchdog Timer |
Yes |
| Indicators |
1 x Power LED,1x HDD LED |
| Controls |
N/A |
| Expansion Slot |
1 x Mini-PCIe (Full size with SIM), 1 x Mini-PCIe (Full size, share with mSATA) |
| System I/O |
|
| USB |
2 x USB 2.0 |
| COM |
2 x COM(2 x RS232) |
| LAN |
2 x Gigabit Ethernet (1 x Intel® I210, 1 x Intel® I219LM ) |
| Display |
N/A |
| Audio |
N/A |
| Storage Support |
|
| HDD |
1 |
| mSATA |
1 |
| Power |
|
| Power Supply |
DC 12V input, M12 connector (optional 9-36V ) |
| Environment |
|
| Opearting Temperature |
0°C ~ 50°C (optional -30°C ) |
| Storage temperature |
-20°C ~ 80°C |
| Relative Humidity |
0% ~ 90% (non-condensing) |
| IP Level |
IP68 |
| Machanical |
|
| Standard Color |
Silver + Black |
| Dimensions |
544 mm(W) x 43.5 mm(D) x 335.5 mm(H) |
| Weight |
7.7 kg |
| Mounting |
VESA |
