| Model name |
IBOX-JSN0 |
| System |
|
| CPU |
Quad-Core ARM® Cortex® A57 MPCore processor |
| GPU |
NVIDIA Maxwell with 128 NVIDIA CUDA Cores |
| System memory |
LPDDR4 4GB-64bit on board |
| Flash |
16Gb of eMMC |
| I/O |
|
| USB |
USB 2.0 x 1, USB 3.0 x 1 |
| COM |
2 x COM (RS-232 x 1, RS485 x 1) |
| LAN |
9 (PoE x 8, GbE x 1) |
| Display |
1 x HDMI, 1 x VGA |
| Audio |
1 x RCA input, 1 x RCA output |
| Storage Support |
|
| HDD |
1 x SSD |
| Expansion |
|
| Mini-PCIe |
2 (1 x full-size, half-size x 1) |
| Power |
|
| Power supply |
DC 9-36V (with ignition pin) |
| Environmental |
|
| Opearting Temperature |
-20°C ~ 65°C |
| Storage Temperature |
-20°C ~ 85°C |
| Relative Humidity |
95% @ 40°C (non-condensing) |
| Mechanical |
|
| Construction |
Aluminum extrusion and heavy-duty steel |
| Standard color |
Black |
| Weight |
1.8 kg |
| Dimensions |
156.6mm(W) x 183.3mm(D) x 50.5mm(H) |
