DLS8500-I
85” TFT LCD, LED Backlight 2000nits, UHD(3840x2160)- Large 85" 4K2K professional signage display
- Support Intel® Smart Display Module (SDM)
- Plug and play with SDM-L and SDM-S CPU boards
- High brightness 2000nits immersive technology
- High color saturation, stunning visual clarity display
- Long lasting 24/7 operations
- Stylish, slim and lightweight design.
- Regular brightness 500 nits available
-
Model Name DLS8500-I Description 85” 2000 nits, 4K2K SDM Solution Size 85” Display Area (mm) 1872(H)*1053(V) Brightness 2000 cd/m² Resolution 3840 x 2160 Aspect Ratio 16:9 Contrast Ratio 400:1 Pixel Pitch (mm) 0.4875(H) x 0.4875(V) Pixel Pre Inch (PPI) 52 Viewing Angle 178°(H),178°(V) Color Saturation (NTSC) 90% Display Colors 1.07 G Response Time (Typical) 9.5ms SDM Slot SDM-S/SDM-L Input Power AC100~240V Power Consumption 60W (Panel Model Only) Dimensions (mm) 890x 890 x 75.7 Bezel Size(U/B/L/R) 15/15/15/15 mm Weight (Net) 80kg Mounting VESA 500x400, 500x600 Operating Temperature 0 ˚C ~ 50 ˚C Storage Temperature -20 ˚C ~ 60 ˚C
