| Model Name |
SSF4470-C |
SSH4470-C |
SSD4470-C |
| Description |
44.7” Resizing LCD, 2000 nits LED backlight, 1920x675 |
| Size |
44.7" |
| Display area (mm) |
1073.779(H) x 377.500(V) |
| Brightness |
2000 cd/m² |
| Resolution |
1920x675 |
| Aspect ratio |
16:5.6 |
| Contrast ratio |
5250:1 |
| Pixel pitch (mm) |
0.559(H) x 0.559(V) |
| Pixel per inch (PPI) |
45 |
| Viewing angle |
178° (H), 178° (V) |
| Color saturation (NTSC) |
83% |
| Display colors |
16.7M |
| Response time (Typical) |
6.5ms |
| Video interface |
LVDS |
DVI, HDMI, DP |
| Input power |
|
AC 100~240V |
| Power consumption |
105W |
110W |
| Dimensions (mm) |
1103 x 410 x 29.2 |
1105.6 x 412.6 x 64.2 |
| Bezel size (U/B/L/R) |
14.2/14.2/12.6/12.6 |
15.5/15.5/13.9/13.9 |
| Weight (Net) |
9 kg |
15.1 kg |
| Mounting |
|
VESA 650x100, 300x75 |
| OSD key |
|
4 Keys (Power Switch, Menu, +, -) |
| OSD control |
|
Brightness, Color, Contrast, Auto Turing, H/V Position…etc |
| Operating temperature |
0°C ~ +50°C |
| Storage temperature |
-20°C ~ +60°C |
